型号 |
承载能力 |
夹臂尺寸 |
开臂尺寸 |
安装等级 |
自重(kg) |
失载距 |
水平重心 |
垂直重心 |
|
Model |
Carrying Capacity |
Size of Clamp Size |
Size of arm stretching |
Installation Grade | Self-weight | Load Loss Distance | Horizontal Center of Gravity | Vertical Center of Gravity |
| (Kg) | A1-A2(mm) | D1-D2(mm) | (Kg) | L(mm) | C2(mm) | C1(mm) | ||
| PCM20A-E13H | 2000 | 890-606 | 580-1350 | 2 | 660 | 195 | 320 | 380 |
| PCM20B-E13H | 2000 | 890-606 | 250-1350 | 2 | 682 | 195 | 330 | 388 |
| PCM20A-E13S | 2000 | 890-606 | 580-1350 | 2 | 675 | 195 | 325 | 380 |
| PCM20B-E13S | 2000 | 890-606 | 250-1350 | 2 | 697 | 195 | 335 | 388 |
| PCM20A-E14H | 2000 | 895-606 | 450-1400 | 2 | 665 | 195 | 320 | 380 |
| PCM20A-E15H | 2000 | 948-677 | 580-1520 | 2 | 700 | 208 | 380 | 383 |
| PCM20B-E15H | 2000 | 948-677 | 250-1520 | 2 | 728 | 208 | 380 | 380 |
| PCM20A-E15S | 2000 | 948-677 | 580-1520 | 2 | 708 | 208 | 383 | 383 |
| PCM20B-E15S | 2000 | 948-677 | 250-1520 | 2 | 735 | 208 | 385 | 380 |
| PCM25A-E13H | 2500 | 890-606 | 580-1350 | 3 | 685 | 235 | 323 | 380 |
| PCM25A-E14H | 2500 | 895-606 | 450-1400 | 3 | 740 | 235 | 323 | 380 |
| PCM25B-E13H | 2500 | 890-606 | 250-1350 | 3 | 700 | 235 | 333 | 388 |
| PCM25A-E13S | 2500 | 890-606 | 580-1350 | 3 | 745 | 235 | 328 | 380 |
| PCM25B-E13S | 2500 | 890-606 | 250-1350 | 3 | 760 | 235 | 338 | 388 |
